1mw gas power generator sets

Price:

Get Latest Price

Min.Order Quantity:

1 Unit/Units

Supply Ability:

500 Unit/Units per Year

Port:

Qingdao gas generator 1mw

Place of Origin:

Shandong, China (Mainland)

Payment Terms:

L/C,T/T

Brand:

NPT

Products Model:

1000GFT

Products Details
Company Profile

Quick Details

Brand Name: NPT

Model Number: 1000GFT

Place of Origin: Shandong, China (Mainland)
Output Type: AC Three Phase
Speed: 1500/1800rpm
Frequency: 50HZ
Rated Power: 1000kw
Rated Voltage: 400/230V
Rated Current: 1800A
Fuel: Natural Gas / bogas/ lpg / biomass
Genset type: OpenType and silent type
Alternator: MBH brushless with AVR
Certificate: ce and iso
Control panel: Smartgen
Intake system: Natural aspiration
Cooling way: Water Radiator
Color: Green

Packaging & Delivery

Packaging Details: Wooden case
Delivery Detail: Within 20 days

Specifications

1mw gas power generator sets

The technical specification of 1mw gas power generator sets :

Generating set general Model		1000GFT
Structure		integral
Exciting method		AVR Brushless
Rated Power (kW)		1000
Rated Current(A)		1800
Rated Voltage(V)		400/230
Rated Frequency(Hz)		50
Rated Power Factor		0.8 LAG
No load voltage setting range		95%-105%
Steady state voltage regulation rate		≤±1%
Transient state voltage regulation rate		≤-15%—+20%
Voltage fluctuation rate		≤3s
Steady state frequency regulation rate		≤±0.5%
Transient state frequency regulation rate		≤±10%
Frequency stabilization time		≤5s
Line-voltage waveform sinusoidal distortion rate		≤2.5%
Gas Engine	Model	NY792D105TL
	Type	Vertical, Vee,4-stroke, electric control ignition, pre-mixed lean burn
	Cylinder number	12
	Bore x Stroke (mm)	200X210
	Total displacement (L)	79.17
	Rated Power (kW)	1200
	Rated Speed (r/min)	1500
	Speed Regulation Mode	Electrical
	Starting Mode	Electrical
	Fuel type	Natural gas
Overall dimension (L x W x H)(mm)		5300X1950X2430
Net weight (kg)		11000

The photo of gas generator:

The advantage of the alternator of generator:

Our patent list of NPT brand gas generator:

Our certificate:

Our customer:
