large torque electric control ball valve 3 way 1 2 3 4 1 for farm work water treatment water saving system

large torque electric control ball valve 3-way 1/2'' 3/4'' 1'' for farm work,water treatment,water saving system

Specification:

Size: 1/4"-2''

Voltage:  DC3-6V,,AC/DC9-24V,AC110V,AC120V,AC220V
Valve body Material: Stainless steel (304, 316), Brass,Ni plated Barss
Open/close time:<12sec
Working pressure: 1.6Mpa/16bar
Torque output: 10NM
Control mode:2,3,5 wires(CR01-CR06)
Valve End:BSP(British Standard)&NPT(ASSI) Thread
Ball Type:T or L flow
Power: maximum 25W
Medium temperature: 0-90°C
Actuator rotation: 90 degree
Rotation direction: double acting
Low Working Current: <80mA
Working Medium:water,air,gas.
Product life: 100,000 times
Special function:position indicator;quick open
                 signal feedback,manual override
                 fail safe(auto-return) function
                 best alternative to the solenoid valves

Features:
 1. Smart shape,perform reliably,brass gear,PPO parts,large output torque,long product life for 100,000 times.
 2. Electrical limit and machinery limit design,accurate position,avoid gear with switch.
 3. Multi-angle assembling,easy to install.
 4. Float ball structure,no leakage,especially suitable for heavy pollution conditions.
 5.Good substitution for solenoid or pneumatic valve.
 6. High protection class,can be worked in moist conditions. IP65.

Material of main parts:
Actuator: heat-resistant ABS
Sealing: PTFE, silicon rubber ball seat, EPDM and NBR stem seat, NBR o-rings
Body: brass or stainless steel
Ball: brass or stainless steel
Stem: brass or stainless steel

Situable for :
1.IC card meters,heat energy meters
2.Air-warm valve.HVAC and fire works.
3.Water equipment,auto-control watersystem,industrial mini-auto equipment, Small equipment for automatic control
4.Irrigation equipment,drinking water equipment,solar water heaters,washing machines,water heaters,industrial humidifier.
6.Solar thermal,under-floor,rain water,irrigation,plumbing service,hot water heating and solar glycol loop,ideal for off-grid system.
 Domestic water,Irrigation system,cooling/heating system,Low voltage plumbing system
7.Multiple voltage and control mode, applicable to a variety of occasions.
